Shuttle XPC cube SH570R8 Barebone System - Socket LGA-1200 - Intel H570 Chip - 128 GB DDR4 SDRAM DDR4-3200/PC4-25600 Maximum RAM Support - 4 Total Memory Slots - Serial ATA/600 Controller - Intel UHD Graphics Graphic(s) - 4 3.5" Bay(s) - 4 SATA Interface(s) - Processor Support (Core i9, Core i7, Core i5, Core i3, Pentium Gold, Celeron) - Gigabit Ethernet - Windows 10, Windows 11, Linux Supported Operating System - 3 USB 3.2 Gen 1 Port(s) - 500 W

Our Product No :   45165

MPN Number :   SH570R8

Manufacturer :  SHUTTLE

Model No :   SH570R8

images

Pre Order

General Information
Manufacturer Shuttle, Inc
Manufacturer Part Number SH570R8
Manufacturer Website Address http://www.shuttle.com
Brand Name Shuttle
Product Line XPC cube
Product Model SH570R8
Product Name BAREBONE XPC cube SH570R8
Marketing Information SUPPORTS 10TH/11TH GENERATION INTEL CORE PROCESSORS AND FOUR HARD DISKS

The Shuttle XPC cube Barebone SH570R8 is able to accommodate up to four 3.5 inch hard drives for enormous storage capacity - ideal for both home and commercial applications. However, this barebones platform is way more than just about storage - the SH570R8 has enough grunt under its aluminium bonnet to be a high-end gaming PC or a workstation for intensive graphics or even video applications. Its black-brushed aluminium case shows how discreet and stylish a powerful PC can look.
Product Type Barebone System
Processor
Processor Socket Socket LGA-1200
Processor Supported
  • Core i9
  • Core i7
  • Core i5
  • Core i3
  • Pentium Gold
  • Celeron
Chipset
Chipset Manufacturer Intel
Chipset Model H570
Memory
Maximum Memory Supported 128 GB
Memory Technology DDR4 SDRAM
Memory Standard DDR4-3200/PC4-25600
Controllers
Controller Type Serial ATA/600
Display & Graphics
Graphics Controller Manufacturer Intel
Graphics Controller Model UHD Graphics
Graphics Memory Technology DDR4 SDRAM
Graphics Memory Accessibility Shared
Network & Communication
Ethernet Technology Gigabit Ethernet
I/O Expansions
Interfaces/Ports
HDMI (Rear) Yes
Total Number of USB Ports 13
USB Type-C (Front) Yes
USB Type-C Detail USB 3.2 Gen Type-C port (5 Gbps)
Operating System
Operating System Supported
  • Windows 10
  • Windows 11
  • Linux
Power Description
Input Voltage
  • 120 V AC
  • 230 V AC
Maximum Power Supply Wattage 500 W
Physical Characteristics
Product Color Black Aluminum
Height 190 mm
Width 215 mm
Depth 332 mm
Weight (Approximate) 3.50 kg
Miscellaneous
Package Contents
  • BAREBONE XPC cube SH510R4
  • Multi-Language XPC Installation Guide (EN, DE, FR, ES, JP, KR, SC, TC)
  • Windows 64-bit Driver Disk
  • 2x Serial Ata Cables
  • Ac Power Cord (With Protective-earth Contacts)
  • Heatsink Compound
  • Protector Cap For The CPU Socket
  • Bag With Screws
Energy Star Yes
Environmentally Friendly Yes
Environmental Certification
  • RoHS
  • ENERGY STAR 5.0
  • ErP
